PRODUCT INTRODUCTION
PRODUCT SPECIFICATION
PRODUCT DETAILS
1. Flexible Playback Options
Plays MP4 files from USB drives (requires proprietary transcoding tool)
Three simultaneous output modes:
HDMI output to displays/monitors
Network streaming via multiple protocols
USB camera emulation (compatible with video conferencing software)
2. Intelligent Playback Control
Supports random/shuffle playback
Manual file navigation (previous/next)
Background playlist management
3. Advanced Streaming & Networking
Ultra-low latency transmission (80-200ms) via PTE private protocol
Supports industry-standard protocols:
RTMP/RTMPS/RTSP
HTTP-TS/HTTP-FLV/HLS
SRT/UDP/RTP multicast
Multi-destination streaming:
Push to up to 6 different RTMP destinations simultaneously
Local servers or live broadcast platforms
Multicast support for multiple LAN viewers
4. Professional Integration
ONVIF-compatible for seamless NVR integration
Supports recording and playback through connected NVR systems
Digital signage and advertising systems
Education and telemedicine solutions
Video conferencing and presentations
Surveillance monitoring centers
Live streaming and broadcast environments
Specification | Parameter | ||
Video input | USB Video | NTFS/EXFAT/FAT32 | MP4 transcoded with a transcoding tool |
Video | Stream | TS | |
HLS | |||
FLV | |||
RTSP | |||
RTMP | |||
UDP | |||
SRT | |||
Private streams | PTE | ||
Push Stream | RTMP(S)/RTSP | ||
SRT | |||
HLS | |||
Audio | G711 | G711A/G711U | |
G711A Over PTE | Disable/Enable | ||
G711A Over RTSP | Disable/Enable/Enable and resample with 8k | ||
Video output | HDMI | 1080P@60/1080P@50/1080P30/1080P25/720P60/720P50/576P50/480P60 | |
USB TYPE-A | 1080P@60/1080P@50/1080P30/720P60/720P50/576P50/480P60 | ||
Audio output | HDMI | 48KHz Dual-channel output | |
3.5MM | Dual-channel output | ||
GB28181 | support | ||
Common | Network | 1000Mbps | |
Configuration | WEB,Upload,Reset | ||
Power Supply | 12V/DC,2A | ||
Power | <1W | ||
Temperature | -20℃+60℃ | ||
Humidity | <90%, non-condened | ||
Size | 8.4cm x 6.5cmx2.8cm | ||
Weight | 141g |
